Replacement headunit mod...Part 2
The headunit is installed and working beautifully. The original post mentioned that the install needed a ground loop isolator; in fact, the install needs 2 ground loop isolators: 1 for the front line level feed and 1 for the rear line level feed.
I also purchased and installed a Terk XMDirect Alpine interface and a Terk XMDirect receiver. This interface connects to the AI-Net bus of the Alpine headunit. The interface also provides an additional AI-Net interface, to which I connected an Alpine KCA-420a iPod interface.
This picture shows the XMDirect Alpine interface:
<img src="http://images12.fotki.com/v214/photos/5/597155/2605229/P9030015-vi.jpg">
The RCA cable and the black cable are connected to the XM receiver which is mounted under the dash.
Here is a picture of the headunit installed:
<img src="http://images12.fotki.com/v216/photos/5/597155/2605229/P9030010-vi.jpg">
A closeup pic:
<img src="http://images12.fotki.com/v214/photos/5/597155/2605229/P9030011-vi.jpg">
Same pic without flash:
<img src="http://images14.fotki.com/v192/photos/5/597155/2605229/P9030012-vi.jpg">
Lastly, a pic with the RISO trim piece:
<img src="http://images12.fotki.com/v216/photos/5/597155/2605229/P9030014-vi.jpg">
I also purchased and installed a Terk XMDirect Alpine interface and a Terk XMDirect receiver. This interface connects to the AI-Net bus of the Alpine headunit. The interface also provides an additional AI-Net interface, to which I connected an Alpine KCA-420a iPod interface.
This picture shows the XMDirect Alpine interface:
<img src="http://images12.fotki.com/v214/photos/5/597155/2605229/P9030015-vi.jpg">
The RCA cable and the black cable are connected to the XM receiver which is mounted under the dash.
Here is a picture of the headunit installed:
<img src="http://images12.fotki.com/v216/photos/5/597155/2605229/P9030010-vi.jpg">
A closeup pic:
<img src="http://images12.fotki.com/v214/photos/5/597155/2605229/P9030011-vi.jpg">
Same pic without flash:
<img src="http://images14.fotki.com/v192/photos/5/597155/2605229/P9030012-vi.jpg">
Lastly, a pic with the RISO trim piece:
<img src="http://images12.fotki.com/v216/photos/5/597155/2605229/P9030014-vi.jpg">
Thread Starter
AudiWorld Super User
Joined: Mar 2003
Posts: 2,203
Likes: 0
I didn't notice any sound degradation from using the isolators >>>
And the pops completely disappeared. There is a product, the PowerDriver PD4 from AudioLink, that was recommended by a professional installer, that will also do the same thing which might be cleaner, but is more expensive...
<a href="http://www.linkmeup.com/pd4.htm">PowerDriver PD4</a>
<a href="http://www.linkmeup.com/pd4.htm">PowerDriver PD4</a>
